| LED Module letter |
Feature:
-Available in 3-LED,4-LED and 6-LED version
-With mounting holes for easy mounting
-Low voltage,energy efficient, virtually no maintenance
-Low heat,high brightness,works well under harsh conditions
-Full range of colors:red,yellow,blue,green,white etc.
-Input voltage:12VDC
-Professionally designedto be fully waterproof
Application:
-Slim design for narrow and compact LED signages .
-Waterproof for outdoor advertising signs, channelletter ,effective contouring ,outdoor waterproof LED lighting projects ,etc |
 |
 |
 |
 |
| Specification: |
| Description |
Voltage(V) |
Current(MA) |
Dimension(L*W*H) |
Viewing angle |
| 3-LED/outdoor |
12 |
20-30 |
80*17*11mm |
75/120 |
| 4-LED/outdoor |
12 |
40-50 |
54*54*11mm |
75/120 |
| 6-LED/outdoor |
12 |
60-75 |
99*54*11mm |
75/120 |
| 3-LED/indoor |
12 |
20-30 |
70*15mm |
75/120 |
| 4-LED/indoor |
12 |
40-50 |
90*15mm |
75/120 |
| 6-LED/indoor |
12 |
60-75 |
128*15mm |
75/120 |
|
| LED Bar & Board |
Features:
-OEM products
-Uitra-bright round LED and super flux LED
-Single color white, green, yellow, red, blue or flashing light
-Size of LED PCB bar/board can be changed according to customer’s requirement
-Supply with necessary wires and connectors
-Alternative 12VDC/24VDC/120VAC/240VAC
-CE/UL approved power supply available upon requirement |
 |
 |
 |
 |
 |
|
